Tomato red drop-leaf island cart

A rolling kitchen island in satin tomato red under a 40mm hard maple butcher block, with three drawers, an open shelf for the mixing bowls and a towel rail. Its 380mm drop leaf folds down flat against the end, so it parks in 960mm of floor and opens to a 1340mm prep counter or a breakfast bar for two; the braked castors take it wherever the cooking is.

Open this design in Crava

Passes Crava's checks for fit, strength and stability. Change any size, the wood or the finish in the app, and it is checked again.

At a glance

Overall W x D x H

1340 x 548 x 900 mm52 3/4" x 21 9/16" x 35 7/16"

Parts to cut

31

Build steps

47

Boards

3

Sheets

4

Solid wood

15.2 bd ft

Weight

85.7 kg189 lb

Materials

• Birch plywood
• Poplar (paint grade)
• Hard maple

Finish

• Finishing oil - Food-safe hardwax oil, matt
• Paint - tomato red, satin

Tools

• Saw
• Square
• Tape
• Router
• Drill
• Table saw
• Clamps
• Sandpaper
• Brush

Hardware and fittings

• 2 x Brass drop-leaf (rule-joint) hinge, 38mm
• 2 x Folding shelf bracket, locking, black steel, 300mm
• 1 x Brass towel rail, 400mm, with two 30mm standoff posts
• 4 x Swivel plate castor with brake, 75mm rubber wheel
• 6 x Side-mount drawer slide, 450mm
• 3 x Round knob, 30mm, brushed brass

Cut list

The first 3 of 23 lines, in millimetres (inches below), finished size including joint allowances.

The 3D model
