Mushroom butler's pantry

A butler's pantry run painted a soft mushroom taupe: face-framed drawers and cupboards with satin nickel pulls under a honed white marble worktop and upstand, and lit glass-fronted wall cabinets that run up to a cove crown, washed underneath with warm light.

Open this design in Crava

Passes Crava's checks for fit, strength and stability. Change any size, the wood or the finish in the app, and it is checked again.

At a glance

Overall W x D x H

3126 x 608 x 2600 mm123 1/16" x 23 15/16" x 102 3/8"

Parts to cut

208

Build steps

145

Boards

21

Sheets

14

Solid wood

31.9 bd ft

Weight

438.4 kg966 lb

Materials

• Birch plywood
• Poplar (paint grade)
• MDF

Finish

• Paint - mushroom, eggshell

Tools

• Saw
• Square
• Tape
• Router
• Clamps
• Drill
• Pocket-hole jig
• Table saw
• Chisel
• Dowel jig
• Sandpaper
• Brush
• 10mm bit
• Cable clips

Hardware and fittings

• 1 x Honed white marble worktop, 20mm, eased edge
• 1 x Honed white marble upstand, 20mm
• 1 x Plug-in under-cabinet LED strip kit, 2700K, in aluminium channels
• 14 x Side-mount drawer slide, 500mm
• 7 x Cup pull, 96mm centres, satin nickel
• 26 x Concealed face-frame hinge, partial overlay
• 10 x Round knob, 30mm, satin nickel
• 4 x Plug-in LED strip kit, 12V, warm white 2700K
• 2 x Toughened glass panel, 4mm
• 4 x Toughened glass panel, 4mm
• 1 x Cove crown moulding, 90mm

Cut list

The first 3 of 144 lines, in millimetres (inches below), finished size including joint allowances.

The 3D model
