Murphy bed library wall

A queen wall bed that folds away behind what looks like four tall Shaker doors, between two bookcases with cupboards below and a row of cupboards bridging over the top. Pull the brass handles and it comes down on its own fold-down leg, lifted by a bought piston kit, with a brass reading light reaching out either side of the pillows. A cove crown runs across the whole wall, and the shelves glow with warm LED strips.

Open this design in Crava

Passes Crava's checks for fit, strength and stability. Change any size, the wood or the finish in the app, and it is checked again.

At a glance

Overall W x D x H

2990 x 611 x 2700 mm117 11/16" x 24 1/16" x 106 5/16"

Parts to cut

118

Build steps

119

Boards

8

Sheets

14

Solid wood

12.5 bd ft

Weight

546.2 kg1204 lb

Materials

• Birch plywood
• MDF
• Poplar (paint grade)

Finish

• Paint - warm white, satin

Tools

• Saw
• Square
• Tape
• Chisel
• Clamps
• Router
• Table saw
• Drill
• Pocket-hole jig
• Dowel jig
• Sandpaper
• Brush
• 10mm bit
• Cable clips

Hardware and fittings

• 12 x Concealed face-frame hinge, partial overlay
• 6 x Round knob, 30mm, brushed brass
• 2 x Plug-in LED strip kit, 12V, warm white 2700K
• 2 x Anti-tip furniture wall bracket, steel, with stud screws
• 1 x Piano hinge, steel, 38mm open
• 2 x Bar pull, 128mm centres, brushed brass
• 1 x Your queen mattress, up to 250mm thick (not part of this build)
• 1 x Vertical wall-bed mechanism kit, queen, piston lift
• 1 x Cove crown moulding, 100mm
• 2 x Plug-in swing-arm reading light, brushed brass

Cut list

The first 3 of 89 lines, in millimetres (inches below), finished size including joint allowances.

The 3D model
