Dust collector closet

A pale mint MDF closet that swallows the loudest, ugliest thing in the shop: the canister collector stands on its bin dolly inside a felt-lined bay, its exhaust leaving through a louvred top section of the door, and rolls out to be emptied. A slim cupboard beside it keeps hoses, blast gates and spare filters, all in one metre of wall.

Open this design in Crava

Passes Crava's checks for fit, strength and stability. Change any size, the wood or the finish in the app, and it is checked again.

At a glance

Overall W x D x H

1144 x 1458 x 2003 mm45 1/16" x 57 3/8" x 78 7/8"

Parts to cut

26

Build steps

50

Boards

1

Sheets

7

Solid wood

0.8 bd ft

Weight

800.6 kg1765 lb

Materials

• MDF
• Poplar (paint grade)

Finish

• Paint - pale mint, satin

Tools

• Saw
• Square
• Tape
• Router
• Drill
• Clamps
• Sandpaper
• Brush

Hardware and fittings

• 1 x Anti-tip furniture wall bracket, steel, with stud screws
• 1 x Acoustic felt panel, 12mm, charcoal
• 1 x Bar pull, 200mm, matt black
• 4 x Concealed cabinet hinge, full overlay, 110 degree
• 1 x Your 1.5kW canister dust collector (not part of this build)
• 1 x Flexible dust hose, 100mm, 1.2m, with clamps
• 1 x Flanged dust port, 100mm
• 1 x Remote-control power switch for the collector, plug-in
• 4 x Concealed cabinet hinge, full overlay
• 1 x Bar pull, 128mm centres, matt black

Cut list

The first 3 of 15 lines, in millimetres (inches below), finished size including joint allowances.
