Butter yellow craft wall

A four-metre craft room wall in soft butter yellow: deep drawers for yarn, a bank of shallow drawers for tools, map drawers for paper and cupboards for fabric bolts, all under a standing-height maple cutting counter with a brass rule set into its front edge. Lit cubbies rise from the counter to the ceiling at each end, with a pegboard, roll rod and maple shelf between them.

Open this design in Crava

Passes Crava's checks for fit, strength and stability. Change any size, the wood or the finish in the app, and it is checked again.

At a glance

Overall W x D x H

4000 x 652 x 2400 mm157 1/2" x 25 11/16" x 94 1/2"

Parts to cut

204

Build steps

124

Boards

10

Sheets

22

Solid wood

51.8 bd ft

Weight

576.9 kg1272 lb

Materials

• Birch plywood
• MDF
• Hard maple

Finish

• Finishing oil - Hardwax oil, matt
• Clear finish - Water-based lacquer, matt
• Paint - butter yellow, eggshell

Tools

• Saw
• Square
• Tape
• Drill
• Dowel jig
• Clamps
• Router
• Table saw
• Chisel
• Sandpaper
• Brush
• 10mm bit
• Cable clips

Hardware and fittings

• 1 x Self-adhesive brass ruler strip, metric
• 38 x Side-mount drawer slide, 550mm
• 19 x Cup pull, 96mm centres, brushed brass
• 4 x Concealed cabinet hinge, full overlay
• 2 x Round knob, 30mm, brushed brass
• 2 x Plug-in LED strip kit, 12V, warm white 2700K

Cut list

The first 3 of 134 lines, in millimetres (inches below), finished size including joint allowances.

The 3D model
